•Operating Parameters
Current Rating : ≤ 15A
Voltage Rating : AC250 V
Times of plug/pull : Above 3000 times
Cable OD Rating : OD ≤ 8.5mm
•Material-ROHS environmental protection material
Cable Type : PVC, PU, Rubber, Silicon
Shell material : Flame-resistant/anti-UV nylon(PA66) RL94V-0
Compression connection type pinhole : Brass
Seal-O-Ring : Silicon
•Propert
Contact resistance : <5mΩ
Dielectric resistance : 500mΩ at DC500V
Wire diameter : 5.0-8.0mm
Pin diameter : 2.35mm
Standing voltage : 3KV Under normal temperature
Operating temperature : -40℃~+105℃
Waterproof Rating : IP68
|
