•Operating Parameters
Current Rating : 15A
Voltage Rating : 220V AC
Times of plug/pull : Above 3000 times
Cable OD Rating : OD≤11.0mm

•Material- ROHS environmental protection material
Cable Type : PVC, PU, Rubber, Silicon
Shell material : Flame-resistant/anti-UV nylon(PA66)
Compression connection type pinhole : Brass
Seal-O-Ring : Silicon

•Property
Contact resistance : <10mΩ
Dielectric resistance : 500mΩ at DC500V
Standing voltage : 3KV Under normal temperature
Operating temperature : -40℃~+105℃
Waterproof Rating : IP68
