Parameter

Symbol

Rating

Unit

IC Power Supply Voltage

VDD

-0.4 ~ +5.5

V

Logic Input Voltage

VI

-0.4~VDD+0.4

V

Rate of data signal

FCLK

15

MHZ

ESD pressure

VESD

2000

V

The max led output Current

IOMAX

18

mA

Soldering Temperature*1

TSD

260

℃

Parameter

Symbol

Min.

Typ.

Max.

Unit

Condition

Luminous Intensity

IV

R

-

230

-

mcd

IF=18mA

G

-

320

-

B

-

80

-

W

270

530

-

Dominant Wavelength

λd

R

615

-

630

nm

G

520

-

535

B

465

-

475

Color Coordinate

x

-

0.2752

-

-

y

-

0.2703

-

-

View Angle

2 θ1/2

-

120

-

deg
