| 3535 3W PC Amber LED |
| | 100% foot print compatible with Cree XP-C / XP-E / XP-G
Best thermal material solution of the world
Best Moisture Sensitivity: JEDEC Level 1
RoHS compliant |
|
|
|
Item No.: AT3535FX-3LEPA
|
Color
|
Part Number
Emitter
|
Luminous Flux ΦV (lm)
|
|
|
@350mA
|
Refer @700mA
|
|
Minimum
|
Typical
|
Typical
|
Typical
|
|
PC Amber
|
AT3535FX-3LEPA
|
80
|
104
|
137
|
186
|
|
Color
|
Forward Voltage VF (V)
|
Thermal Resistance Junction to Slug (°C/ W)
|
|
@ 350mA
|
Refer @700mA
|
|
Min.
|
Typ.
|
Max.
|
Typ.
|
|
PC Amber
|
2.85
|
3.20
|
3.60
|
3.60
|
8
|
|
Radiation
Pattern
|
Color
|
Dominant Wavelength λD
|
Total
Included Angle (degrees) θ0.90V
|
Viewing Angle (degrees)
2 θ1/2
|
|
Min.
|
Typ.
|
Max.
|
|
Lambertian
|
PC Amber
|
585.4 nm
|
588.3 nm
|
591.2 nm
|
160
|
130
|
| |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Enviroment
Operation Temperature: -40°C ~ 90°C
Storage Temperature: -40°C ~ 120°C
Please contact us for more detail.
